Zhengzhou Meishuo’s 200 tph mobile crushing line makes a powerful debut in Mongolia, conquering diverse operating conditions with superior quality!
[News Overview] Recently, a high-efficiency mobile crushing and screening production line with a capacity of 200 tons per hour—meticulously crafted by Zhengzhou Meishuo—was successfully delivered and put into operation in Mongolia. Facing Mongolia's vast and varied terrain, Zhengzhou Meishuo leveraged its superior wheeled mobile chassis design and robust crushing and screening performance to deliver a solution characterized by high capacity, low energy consumption, and easy relocation. This achievement once again demonstrates Zhengzhou Meishuo’s formidable strength in the high-end mining crushing sector.
A Powerful Combination: A Scientifically Optimized 445kW Closed-Loop Crushing Workflow
The project delivered to the Mongolian client features a design capacity of 200 tons per hour. To perfectly match local hard rock characteristics and meet high standards for finished aggregates, Zhengzhou Meishuo’s engineering team tailored a classic two-stage configuration: a primary jaw crusher followed by a secondary impact crusher with screening. With a combined power output of 445 kW, the two mobile units integrate seamlessly to form a scientific, smooth, and highly efficient closed-loop crushing production line.
1. Primary Mobile Crushing Station: A Robust and Reliable "Trailblazer"
Serving as the first stage of the entire system, the primary mobile crushing station (total power: 143 kW) handles the critical task of coarse crushing large raw stones.
Core Unit: Equipped with a high-power (110 kW) PE750×1060 jaw crusher, offering exceptional feed intake and crushing capabilities.
Feeding and Conveying: Features a 15 kW GF1245 vibrating feeder and a B1000 discharge belt conveyor (utilizing a high-performance K-series gear reducer) to ensure smooth, continuous material transport.
Safety Assurance: Comes standard with an RCYD-10 self-discharging iron remover (3 kW), capable of efficiently extracting iron impurities from the material, thereby ensuring the safe and uninterrupted operation of the downstream secondary equipment. 2. NK1315-S4 Secondary Impact Crushing and Screening Mobile Station: A "Shaping Master" for Precision Processing
Material that has undergone primary crushing enters the NK1315-S4 secondary station (total power: 302 kW) for high-precision fine crushing and screening, yielding high-quality aggregates with excellent particle shape.
Core Crushing Unit: Features the PFW1315 impact crusher (powered by a robust 220 kW motor and hydraulic station). It utilizes impact energy to crush material, producing perfectly cubic finished products free from internal stress or cracks, thereby significantly enhancing the economic value of the aggregates.
High-Efficiency Screening: Equipped with a 30 kW 4YK2170 vibrating screen and multiple high-quality conveyor belts (including feed, upper-deck screening, and finished product belts—all utilizing K-series gear reducers), the system ensures precise grading and rapid discharge of aggregates in various specifications.
Core Value and Project Highlights: Why Choose Zhengzhou Meishuo?
In this Outer Mongolia project, Zhengzhou Meishuo’s mobile crushing stations demonstrated three core competitive advantages, creating immense commercial value for the client:
Superior Mobility and Relocation Capability: Tackling Field Challenges with Ease
To address the project's dispersed site locations and complex terrain, both units feature an advanced wheeled mobile chassis design. Equipped with standard dual-axle assemblies, a 50/90 kingpin, and JXT-2 hydraulic lifting outriggers, the units allow for rapid, "ready-to-go" relocation using just a single towing vehicle. This drastically cuts infrastructure setup time and transportation costs, enabling quick project commissioning.
High Quality and Durability: Minimizing Total Lifecycle Costs
In harsh operating environments, equipment stability equates to corporate profit. Key structural components of the Meishuo mobile station (such as hoppers and chassis frames) are manufactured using high-quality, high-strength materials (National Standards Q355B and Q235B). Furthermore, the entire line incorporates high-performance K-series gear reducers and advanced electrical control systems. This ensures the equipment is not only resistant to pressure and wear but also capable of continuous, stable operation with a low failure rate, significantly reducing long-term maintenance costs. 200 t/h Gold Processing Capacity: Maximizing Efficiency
The seamless synergy between the primary and secondary stations breaks the rigid mold of traditional fixed production lines. With optimized power distribution and stable, high-output performance, a steady supply of premium manufactured sand and aggregate is delivered directly to the project site. This provides a robust foundation for clients to accelerate capital recovery and enhance their market competitiveness.
Conclusion
The successful commissioning of the Outer Mongolia project marks another significant milestone in Zhengzhou Meishuo’s journey toward global expansion. Moving forward, Zhengzhou Meishuo remains committed to the philosophy of "Precision Manufacturing and Quality First." We will continue to provide global clients with smarter, more efficient, and eco-friendly integrated crushing solutions, empowering every partner to turn stone into gold amidst the changing tides of the industry and achieve shared success.
(For detailed specifications and pricing regarding Zhengzhou Meishuo’s mobile crushing stations, please call our service hotline or consult with our online customer service team.)
